AIC RSC-4ET-01 - 4U 24x 3.5" hot-swap bays, 1200W CRPS redundant power, 2x 2.5" hot-swap OS, rail, 4U24 SAS 12G expander

SKU: CAAICRSC-4ET00-01
Brand: AIC
4U 24x 3.5" hot-swap bays, tool-less 3.5" and 2.5" HDD tray, 1200W CRPS redundant power supply, 2x 2.5" hot-swap OS, rail, 4U24 SAS 12G expander controller on backplane (3X series)
Price: $1,560.00
AIC RSC-4ET-01 - 4U 24x 3.5" hot-swap bays, 1200W CRPS redundant power, 2x 2.5" hot-swap OS, rail, 4U24 SAS 12G expander
AIC RSC-4ET-01 - 4U 24x 3.5" hot-swap bays, 1200W CRPS redundant power, 2x 2.5" hot-swap OS, rail, 4U24 SAS 12G expander
AIC RSC-4ET-01 - 4U 24x 3.5" hot-swap bays, 1200W CRPS redundant power, 2x 2.5" hot-swap OS, rail, 4U24 SAS 12G expander
AIC RSC-4ET-01 - 4U 24x 3.5" hot-swap bays, 1200W CRPS redundant power, 2x 2.5" hot-swap OS, rail, 4U24 SAS 12G expander
AIC RSC-4ET-01 - 4U 24x 3.5" hot-swap bays, 1200W CRPS redundant power, 2x 2.5" hot-swap OS, rail, 4U24 SAS 12G expander
AIC RSC-4ET-01 - 4U 24x 3.5" hot-swap bays, 1200W CRPS redundant power, 2x 2.5" hot-swap OS, rail, 4U24 SAS 12G expander
AIC RSC-4ET-01 - 4U 24x 3.5" hot-swap bays, 1200W CRPS redundant power, 2x 2.5" hot-swap OS, rail, 4U24 SAS 12G expander
AIC RSC-4ET-01 - 4U 24x 3.5" hot-swap bays, 1200W CRPS redundant power, 2x 2.5" hot-swap OS, rail, 4U24 SAS 12G expander
AIC RSC-4ET-01 - 4U 24x 3.5" hot-swap bays, 1200W CRPS redundant power, 2x 2.5" hot-swap OS, rail, 4U24 SAS 12G expander
AIC RSC-4ET-01 - 4U 24x 3.5" hot-swap bays, 1200W CRPS redundant power, 2x 2.5" hot-swap OS, rail, 4U24 SAS 12G expander
(Click to see larger image and other views)
Product Details

RSC-4ET is a T series 4U 24-bay SAS/SATA storage server chassis. With its tool-less 3.5" and 2.5" hard drive carriers, top covers and backplane, the RSC-4ET supports quick installation and easy maintenance. This tool-less design solution also features 3 x hot swap fans designed to minimize rotational vibration and SPGC pre-plated steel with minimal paint, offering a cost-effective solution ideally suited for a broad range of applications.  (Power supply is included. Motherboard is not included.)


Key Features
• Tool-less design supports quick installation and easy maintenance:
- Tool-less 3.5” & 2.5” drive trays
- Tool-less top covers
- Tool-less backplane
- Tool-less slide rails
• 12Gb/s SAS expander chip on backplane
• Specially designed hot swap and low power consumption fans minimize rotational vibration and provide superior cooling
• 3.5” drive tray comes with 4 screw holes to adapt to 2.5” drive
• Comes with a redundant PSU 80+ Platinum
• Two front access USB 3.0 portsm

Dimensions (W x D x H)
• mm: 430 x 680 x 174.3
• inches: 16.9 x 26.8 x 6.9
Industry Standard
EIA-RS310D
Material
Heavy-duty preplated SPGC cold-rolled steel
Color
Front Panel: Black
Cooling
Middle: 3 x 120x25mm PWM hot swap fans
Power Supply
1200W 1+1 redundant PSU 80+ Platinum
Expansion Slots
7 full height
Front Panel
System power on/off, System reset and 2 x USB 3.0 ports
LED Indicators
Power, LAN, Drive and Alert
System Board
12”(W) x 13”(D) E-ATX/SSI EEB 3.6 compliant MB
Drive Bays
• External: 24 x 3.5” hot swap
Options choose 1:
• Internal: 2 x 2.5”
• External: 2 x 2.5” hot swap
Backplane
1 x 24-port 12Gb SATA/SAS backplane with 36-PHY expander chip and 3 SFF-8643 connectors
Storage Temperature
0°C(32°F) ~ 50°C(122°F)
Humidity
5% ~ 95% non-condensing
Gross Weight (w/ PSU & Rail)
• kgs: 37
• lbs: 81.6
Package Dimension (W x D x H)
• mm: 645 x 835 x 310
• inches: 25.4 x 32.9 x 12.2
