IM2S3168-512GCTB5 - 512GB M.2 SATA

Product Features

• P/E cycle upgrade to 3K improved endurance and reliability
• 3D NAND flash for enhanced capacity, durability, and power efficiency
• LDPC ECC Technology
• Supports AES 256-bit Encryption and TCG Opal 2.0
• End-to-End (E2E) Data Path Protection

• Suitable for Servers, Data Centers, Surveillance, Transportation, IPCs

Specifications:

Form Factor M.2 2280 Capacity 64GB - 1TB Interface SATA III Flash Type 3D TLC Dimensions (L x W x H) 80 x 22 x 3.6mm Sequential Read (Max*) 560MB/s Sequential Write (Max*) 520MB/s Operating Temperature (Standard) 0ºC to 70ºC Operating Temperature (Industrial) -40ºC to 85ºC Operating Temperature (Extended) - Operating Voltage 3.3V Power Consumption 1.58W Shock Resistance 1500G/0.5ms, Half Sine Wave Operating Humidity 5%-95% RH, non-condensing Vibration Resistance 20G (20-2000Hz) Technologies LDPC ECC, DEVSLP, SLC Cache, AES 256-bit Encryption, Thermal Throttling, S.M.A.R.T. Monitor, NCQ and TRIM Command
